About The Trek Marlin+ 8 Mountain E-Bike

The Trek Marlin+ 8 is a Bosch Active Line Plus e-MTB with a component spec built around trail performance. It shares the same 50Nm motor and 400Wh CompactTube battery as the Marlin+ 6 but steps up with a 12-speed Shimano Deore drivetrain, 4-piston hydraulic disc brakes, a RockShox Recon Silver RL fork, and tubeless-ready wheels with wider 29x2.60" tires. These changes give riders more control on demanding terrain without fundamentally changing the character of the bike.

The RockShox Recon Silver RL with Motion Control damper and Solo Air spring offers more tuning range than a basic coil fork, and the Shimano Deore 10-51 cassette expands the gear range for steeper climbs. The tubeless-ready Bontrager Line TLR 30 rims and Gunnison Pro XR tires allow you to run lower pressures for better grip, and the Shimano MT4100/MT420 4-piston brake system provides consistent stopping power under load. Like the Marlin+ 6, the frame includes a dropper post, rack/fender/kickstand mounts, and AUTO mode adaptive assist.

Who It's For

  • Trail riders who want a capable e-MTB and plan to run tubeless from the start
  • Riders who prioritize braking performance and want 4-piston calipers over 2-piston
  • Riders who want a 12-speed drivetrain for a wider gear range and more precise cadence control
  • Anyone stepping up from the Marlin+ 6 who wants more trail-oriented components without moving to a full-suspension bike

What to Look For

  • The tubeless-ready wheel and tire setup is one of the most meaningful upgrades over the Marlin+ 6 — running tubeless reduces pinch flat risk and allows lower tire pressures for better grip
  • The 12-speed Shimano Deore drivetrain offers a wider 10-51 range; useful if your terrain includes long climbs or fast descents where gear selection matters
  • The RockShox Recon Silver RL fork's Motion Control damper gives more adjustability than a basic lockout-only fork

Key Features

Frame: Alpha Gold Aluminum with tapered head tube, internal routing, UDH derailleur hanger, Boost148 rear spacing, and 12mm thru axle. Rack, fender, and kickstand mounts built in.

Motor & Battery: Bosch Active Line Plus motor with 50Nm torque and AUTO adaptive mode. Bosch CompactTube 400Wh battery. PowerMore range extender compatible. UL certified e-system.

Fork: RockShox Recon Silver RL with Solo Air spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110 spacing, 15mm Maxle Stealth, and 120mm travel.

Drivetrain: Shimano Deore M6100 12-speed rear derailleur (long cage), Shimano Deore M6100 shifter, Shimano Deore M6100 10-51 cassette, Shimano Deore M6100 12-speed chain, and 32T FSA steel chainring.

Brakes: Shimano 4-piston hydraulic disc brakes with MT4100 levers and MT420 calipers. Shimano RT64 centerlock rotors at 203mm front and rear.

Wheels: 29" wheels with Bontrager Line TLR 30 tubeless-ready 28-hole rims, Bontrager TLR rim strip, Shimano TC500 centerlock hubs with Boost spacing, and Bontrager Gunnison Pro XR 29x2.60" tubeless-ready dual compound aramid bead tires (60 tpi).

Rider Intent Summary

  • Biggest strengths: Tubeless-ready wheels and tires, 4-piston brakes, 12-speed wide-range drivetrain, and RockShox fork with Motion Control damping — all spec'd for more demanding trail use
  • Tradeoffs: Hardtail geometry means the motor and component upgrades matter most on moderate to moderate-plus terrain; riders on technical trails with significant chunk may eventually want full suspension
  • What makes it different: The jump from 2-piston to 4-piston brakes, 9-speed to 12-speed, and wire bead to tubeless-ready tires represents a meaningful step up in trail capability over the Marlin+ 6

Victory's Take

At Victory Bicycle Studio, we consider the Marlin+ 8 the stronger trail choice of the two — the tubeless-ready wheels and 4-piston brakes make a noticeable difference on the descents where you're actually relying on this bike.

What you get

  • Frame - Alpha Gold Aluminum, hardtail, modern geometry
  • Fork - RockShox Recon Silver RL, Solo Air, 120mm
  • Motor - Bosch Active Line Plus, 50Nm Smart System
  • Battery - 400Wh CompactTube, PowerMore compatible
  • Drivetrain - Shimano Deore 12-speed, 10-51 cassette
Marlin+ 8 US L 29 Purple Flip to Black Fade

Trek

Trek Marlin+ 8 Mountain E-Bike

Regular price $3,999.99 USD
Sale price $3,999.99 USD Regular price $3,999.99 USD

Specifications

Frameset
Frame

Alpha Gold Aluminum, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle

- Size: XS - Curved top tube

Fork

RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, Boost110, 15mm Maxle Stealth

- Size: XS - 46mm offset, 100mm travel

- Size: S - 46mm offset, 120mm travel

- Size: M, L, XL - 42mm offset, 120mm travel

Wheels
Front Hub

Shimano TC500 alloy, centerlock, 110x15mm thru axle

Rear Hub

Shimano TC500 alloy, centerlock, 148x12mm thru axle

Rear Thru Axle

Bontrager Switch thru axle, removable lever

Rim

Bontrager Line TLR 30, Tubeless Ready, Presta valve

- Size: XS, S - 28-hole

- Size: M, L, XL - 32-hole

Tire

Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi

- Size: XS, S - 27.5x2.60"

- Size: M, L, XL - 29x2.60"

Rim Strip

Bontrager TLR

Max Tire Size

Frame: 29x2.60" (XS: 27.5x2.60"), Fork: See manufacturer

Drivetrain and Brakes
Shifter

Shimano Deore M6100, 12 speed

Rear Derailleur

Shimano Deore M6100, long cage

Crank

FSA CK-220, 165mm length

Chainring

FSA, 32T, steel

Cassette

Shimano Deore M6100, 10-51, 12 speed

Chain

Shimano Deore M6100, 12 speed

Pedals

Nylon platform

Brake Set

Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper

Brake Rotor

Shimano RT64, centerlock, 203mm

Cockpit
Saddle

Bontrager Verse P3, chromoly rails

Seatpost

TranzX JD-YSI34, internal routing, 31.6mm

- Size: XS, S - 100mm travel, 350mm length

- Size: M, L - 150mm travel, 456mm length

- Size: XL - 170mm travel, 500mm length

Handlebar

Bontrager alloy, 31.8mm

- Size: XS, S - 15mm rise, 720mm width

- Size: M, L, XL - Bontrager Comp, 40mm rise, 780mm width

Grips

Trek Line Comp, nylon lock-on

Stem

Bontrager Comp, 31.8mm, 7 degree

- Size: XS, S - 35mm length

- Size: M, L - Blendr compatible, 50mm length

- Size: XL - Blendr compatible, 60mm length

Headset

Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom

Additional Information
Motor

Bosch Active Line Plus

Battery

Bosch CompactTube 400Wh

Charger

Bosch standard 2A, 110V, smart system

Display

Bosch Purion 200

E-bike Class

Class 1

Weight

M - 21.89 kg / 48.26 lbs (with TLR sealant, no tubes)

Weight Limit

300 lbs (136 kg) maximum total weight (rider, bicycle, and cargo)
